medical Hero Product Manufactured in-house
Ultra-Low Temperature Freezers
-86°C to -40°C Key Features
Add-on features (available at additional cost)
LN2/CO2 backup port Automatic defrost Printer port Voltage stabiliser Cryo boxes Cryo gloves Ice scraper
Gallery
Technical Specifications
Type
Upright / Vertical
Temperature Range
-80°C
Insulation
130-150 mm high density polyurethane foam, VIP option
Construction
Outer galvanized steel with epoxy coating; Inner SS-304
Refrigeration
Cascade dual compressor system, non-CFC/HCFC
Control System
TFT touchscreen, 365-day data storage, USB & PC interface
Power Supply
220-240 V, 50 Hz
Alarms
Battery-operated audio/visual for power failure, high/low temp, door open
Product Models
| Type | Model | Capacity | Exterior Dimensions |
|---|---|---|---|
| Under-Counter | ULT-100UC | 100 L | 990 x 900 x 727 mm |
| Vertical | ULT-333V | 333 L | 1781 x 737 x 964 mm |
| Vertical | ULT-427V | 427 L | 2066 x 737 x 964 mm |
| Vertical | ULT-549V | 549 L | 2066 x 867 x 964 mm |
| Vertical | ULT-685V | 685 L | 2066 x 1012 x 964 mm |
| Vertical | ULT-817V | 817 L | 2066 x 1154 x 964 mm |
| Vertical | ULT-953V | 953 L | 2066 x 1299 x 964 mm |
| Chest | ULT-465C | 465 L | 1020 x 1535 x 1140 mm |
| Chest | ULT-710C | 710 L | — |
Dimensions are site-specific and customisable to requirements.
Request spec sheetEnquire about this product
Get pricing, technical specs, or schedule a call with our engineering team.
Request Quote Contact on WhatsAppApplications
Biobanking
Plasma storage
Pharmaceutical R&D
Enzyme storage
Vaccine research
Certifications
ISO 13485CDSCOIEC
